Agent Harness: Tool Call Flow

A keyboard sends a question to a local computer running the application harness. The harness calls an external LLM API, receives a tool request, validates that list_directory is available in its local tool registry, runs ls src/components, sends the three returned filenames back to the API, and presents DemoReplayButton.tsx, NPlusOneQueryDemos.tsx, and TableOfContents.tsx to the person.

Tool calling lets an LLM request an action from application code.

The application gives the model a system prompt describing the available tool and the exact shape of a tool request:

You can use `list_directory` to list files in an approved directory.
When the user asks for a directory listing, respond with only JSON in this shape:
{"name":"list_directory","arguments":{"path":"..."}}
After the tool result arrives, answer the user in plain language.

The user prompts the model:

What files are in src/components?

The LLM emits a simplified tool request that the harness recognizes:

{
  "name": "list_directory",
  "arguments": {
    "path": "src/components"
  }
}

Note: This JSON is a simplified application-level protocol. Pi and Rig expose the same conceptual stages through framework-specific tool definitions and execution results.

The harness calls the tool like this:

use serde_json::json;
use std::{error::Error, fs, io};

fn list_directory(directory: &str) -> io::Result<Vec<String>> {
    let mut entries = fs::read_dir(directory)?
        .map(|entry| Ok(entry?.file_name().to_string_lossy().into_owned()))
        .collect::<io::Result<Vec<_>>>()?;
    entries.sort();
    Ok(entries)
}

fn list_directory_tool(directory: &str) -> Result<String, Box<dyn Error>> {
    let entries = list_directory(directory)?;
    Ok(serde_json::to_string_pretty(&json!({ "entries": entries }))?)
}

fn harness() -> Result<(), Box<dyn Error>> {
    println!("{}", list_directory_tool("src/components")?);
    Ok(())
}

In the fixture used by this example, the directory contains these three entries:

$ ls -1 src/components
DemoReplayButton.tsx
NPlusOneQueryDemos.tsx
TableOfContents.tsx

The harness appends this tool result to the conversation. The model can then answer the user's question in plain language.

{
  "entries": [
    "DemoReplayButton.tsx",
    "NPlusOneQueryDemos.tsx",
    "TableOfContents.tsx"
  ]
}

The LLM can then give the user a concise final answer:

The src/components directory contains three files:
- DemoReplayButton.tsx
- NPlusOneQueryDemos.tsx
- TableOfContents.tsx
